mdadm命令詳解
mdadm命令詳解及實驗過程
在線學習視頻分享：linux視頻教程
一.概念
? ? ? ? mdadm是multiple devices admin的簡稱，它是linux下的一款標準的軟件 RAID 管理工具，作者是Neil Brown
二.特點
? ? ? ? mdadm能夠診斷、監控和收集詳細的陣列信息 ?
? ? ? ? mdadm是一個單獨集成化的程序而不是一些分散程序的集合，因此對不同RAID管理命令有共通的語法 ?
? ? ? ? mdadm能夠執行幾乎所有的功能而不需要配置文件(也沒有默認的配置文件）
三.作用 （引用） ? ? ? ?
? ? ? ? 在linux系統中目前以MD(Multiple Devices)虛擬塊設備的方式實現軟件RAID,利用多個底層的塊設備虛擬出一個新的虛擬設備,并且利用條帶化(stripping)技術將數據塊均勻分布到多個磁盤上來提高虛擬設備的讀寫性能,利用不同的數據冗祭算法來保護用戶數據不會因?yàn)槟硞€(gè)塊設備的故障而完全丟失,而且還能在設備被替換后將丟失的數據恢復到新的設備上.
? ? ? ? 目前MD支持linear,multipath,raid0(stripping),raid1(mirror),raid4,raid5,raid6,raid10等不同的冗余級別和級成方式,當然也能支持多個RAID陳列的層疊組成raid1 0,raid5 1等類型的陳列
四.實驗
? ? 試題：建立4個大小為1G的磁盤，并將其中3個創建為raid5的陣列磁盤，1個為熱備份磁盤。測試熱備份磁盤替換陣列中的磁盤并同步數據。移除損壞的磁盤，添加一個新磁盤作為熱備份磁盤。最后要求開機自動掛載。
4.1創建磁盤
?[root@xiao?~]#?fdisk?/dev/sda WARNING:?DOS-compatible?mode?is?deprecated.?It's?strongly?recommended?to ?????????switch?off?the?mode?(command?'c')?and?change?display?units?to ?????????sectors?(command?'u'). Command?(m?for?help):?n First?cylinder?(10486-13054,?default?10486):? Using?default?value?10486 Last?cylinder,?+cylinders?or?+size{K,M,G}?(10486-13054,?default?13054):?+1G Command?(m?for?help):?n First?cylinder?(10618-13054,?default?10618):? Using?default?value?10618 Last?cylinder,?+cylinders?or?+size{K,M,G}?(10618-13054,?default?13054):?+1G Command?(m?for?help):?n First?cylinder?(10750-13054,?default?10750):? Using?default?value?10750 Last?cylinder,?+cylinders?or?+size{K,M,G}?(10750-13054,?default?13054):?+1G Command?(m?for?help):?n First?cylinder?(10882-13054,?default?10882):? Using?default?value?10882 Last?cylinder,?+cylinders?or?+size{K,M,G}?(10882-13054,?default?13054):?+1G Command?(m?for?help):?t Partition?number?(1-8):?8 Hex?code?(type?L?to?list?codes):?fd Changed?system?type?of?partition?8?to?fd?(Linux?raid?autodetect) Command?(m?for?help):?t Partition?number?(1-8):?7 Hex?code?(type?L?to?list?codes):?fd Changed?system?type?of?partition?7?to?fd?(Linux?raid?autodetect) Command?(m?for?help):?t Partition?number?(1-8):?6 Hex?code?(type?L?to?list?codes):?fd Changed?system?type?of?partition?6?to?fd?(Linux?raid?autodetect) Command?(m?for?help):?t Partition?number?(1-8):?5?? Hex?code?(type?L?to?list?codes):?fd Changed?system?type?of?partition?5?to?fd?(Linux?raid?autodetect) Command?(m?for?help):?p? Disk?/dev/sda:?107.4?GB,?107374182400?bytes 255?heads,?63?sectors/track,?13054?cylinders Units?=?cylinders?of?16065?*?512?=?8225280?bytes Sector?size?(logical/physical):?512?bytes?/?512?bytes I/O?size?(minimum/optimal):?512?bytes?/?512?bytes Disk?identifier:?0x0008ed57 ???Device?Boot??????Start?????????End??????Blocks???Id??System /dev/sda1???*???????????1??????????26??????204800???83??Linux Partition?1?does?not?end?on?cylinder?boundary. /dev/sda2??????????????26???????10225????81920000???83??Linux /dev/sda3???????????10225???????10486?????2097152???82??Linux?swap?/?Solaris /dev/sda4???????????10486???????13054????20633279????5??Extended /dev/sda5???????????10486???????10617?????1058045???fd??Linux?raid?autodetect /dev/sda6???????????10618???????10749?????1060258+??fd??Linux?raid?autodetect /dev/sda7???????????10750???????10881?????1060258+??fd??Linux?raid?autodetect /dev/sda8???????????10882???????11013?????1060258+??fd??Linux?raid?autodetect Command?(m?for?help):?w The?partition?table?has?been?altered! Calling?ioctl()?to?re-read?partition?table. WARNING:?Re-reading?the?partition?table?failed?with?error?16:?設備或資源忙. The?kernel?still?uses?the?old?table.?The?new?table?will?be?used?at the?next?reboot?or?after?you?run?partprobe(8)?or?kpartx(8) Syncing?disks.
4.2加載內核
[root@xiao ~]# partx -a /dev/sda5 /dev/sda
[root@xiao ~]# partx -a /dev/sda6 /dev/sda
[root@xiao ~]# partx -a /dev/sda7 /dev/sda
[root@xiao ~]# partx -a /dev/sda8 /dev/sda
4.3創建raid5及其熱備份盤
[root@xiao?~]#?mdadm?-C?/dev/md0?-l?5?-n?3?-x?1???/dev/sda{5,6,7,8} mdadm:?/dev/sda5?appears?to?be?part?of?a?raid?Array: ????level=raid5?devices=3?ctime=Wed?Dec?17?00:58:24?2014 mdadm:?/dev/sda6?appears?to?be?part?of?a?raid?array: ????level=raid5?devices=3?ctime=Wed?Dec?17?00:58:24?2014 mdadm:?/dev/sda7?appears?to?be?part?of?a?raid?array: ????level=raid5?devices=3?ctime=Wed?Dec?17?00:58:24?2014 mdadm:?/dev/sda8?appears?to?be?part?of?a?raid?array: ????level=raid5?devices=3?ctime=Wed?Dec?17?00:58:24?2014 Continue?creating?array??y mdadm:?Defaulting?to?version?1.2?metadata mdadm:?array?/dev/md0?started.
4.4初始化時間和磁盤陣列的讀寫的應用相關，使用cat /proc/mdstat信息查詢RAID陣列當前重構的速度和預期的完成時間。
[root@xiao?~]#?cat?/proc/mdstat Personalities?:?[raid1]?[raid0]?[raid6]?[raid5]?[raid4]? md0?:?active?raid5?sda7[4]?sda8[3](S)?sda6[1]?sda5[0] ??????2113536?blocks?super?1.2?level?5,?512k?chunk,?algorithm?2?[3/2]?[UU_] ??????[=========>...........]??recovery?=?45.5%?(482048/1056768)?finish=0.3min?speed=30128K/sec ?????? unused?devices:?<none> [root@xiao?~]#?cat?/proc/mdstat Personalities?:?[raid1]?[raid0]?[raid6]?[raid5]?[raid4]? md0?:?active?raid5?sda7[4]?sda8[3](S)?sda6[1]?sda5[0] ??????2113536?blocks?super?1.2?level?5,?512k?chunk,?algorithm?2?[3/3]?[UUU] ?????? unused?devices:?<none> ?[root@xiao?~]#?mke2fs?-t?ext3?/dev/md0????????//格式化raid</none></none>
4.5掛載raid到/mnt目錄下，并查看是否正常（顯示lost+found為正常）
[root@xiao?~]#?mount?/dev/md0?/mnt [root@xiao?~]#?ls?/mnt lost+found
?
4.6查看raid陣列的詳細信息
[root@xiao?~]#?mdadm?-D?/dev/md0 /dev/md0: ????????Version?:?1.2 ??Creation?Time?:?Wed?Dec?17?03:38:08?2014 ?????Raid?Level?:?raid5 ?????Array?Size?:?2113536?(2.02?GiB?2.16?GB) ??Used?Dev?Size?:?1056768?(1032.17?MiB?1082.13?MB) ???Raid?Devices?:?3 ??Total?Devices?:?4 ????Persistence?:?Superblock?is?persistent ????Update?Time?:?Wed?Dec?17?03:55:11?2014 ??????????State?:?clean? ?Active?Devices?:?3 Working?Devices?:?4 ?Failed?Devices?:?0 ??Spare?Devices?:?1 ?????????Layout?:?left-symmetric ?????Chunk?Size?:?512K ???????????Name?:?xiao:0??(local?to?host?xiao) ???????????UUID?:?bce110f2:34f3fbf1:8de472ed:633a374f ?????????Events?:?18 ????Number???Major???Minor???RaidDevice?State ???????0???????8????????5????????0??????active?sync???/dev/sda5 ???????1???????8????????6????????1??????active?sync???/dev/sda6 ???????4???????8????????7????????2??????active?sync???/dev/sda7 ???????3???????8????????8????????-??????spare???/dev/sda8
4.7模擬損壞其中的一個磁盤，這里我選擇 ?/dev/sda6磁盤
[root@xiao?~]#?mdadm?/dev/md0?--fail?/dev/sda6 mdadm:?set?/dev/sda6?faulty?in?/dev/md0
4.7查看raid陣列詳細信息，發現/dev/sda8自動替換了損壞的/dev/sda6磁盤。
[root@xiao?~]#?mdadm?-D?/dev/md0 /dev/md0: ????????Version?:?1.2 ??Creation?Time?:?Wed?Dec?17?03:38:08?2014 ?????Raid?Level?:?raid5 ?????Array?Size?:?2113536?(2.02?GiB?2.16?GB) ??Used?Dev?Size?:?1056768?(1032.17?MiB?1082.13?MB) ???Raid?Devices?:?3 ??Total?Devices?:?4 ????Persistence?:?Superblock?is?persistent ????Update?Time?:?Wed?Dec?17?04:13:59?2014 ??????????State?:?clean,?degraded,?recovering? ?Active?Devices?:?2 Working?Devices?:?3 ?Failed?Devices?:?1 ??Spare?Devices?:?1 ?????????Layout?:?left-symmetric ?????Chunk?Size?:?512K ?Rebuild?Status?:?43%?complete ???????????Name?:?xiao:0??(local?to?host?xiao) ???????????UUID?:?bce110f2:34f3fbf1:8de472ed:633a374f ?????????Events?:?26 ????Number???Major???Minor???RaidDevice?State ???????0???????8????????5????????0??????active?sync???/dev/sda5 ???????3???????8????????8????????1??????spare?rebuilding???/dev/sda8 ???????4???????8????????7????????2??????active?sync???/dev/sda7 ???????1???????8????????6????????-??????faulty???/dev/sda6 [root@xiao?~]#?cat?/proc/mdstat Personalities?:?[raid1]?[raid0]?[raid6]?[raid5]?[raid4]? md0?:?active?raid5?sda7[4]?sda8[3]?sda6[1](F)?sda5[0]
? ? ? 2113536 blocks super 1.2 level 5, 512k chunk, algorithm 2 [3/3] [UUU] ? #正常的情況會是[UUU],若第一個磁盤損壞則顯示[ _UU ].
4.8 移除損壞的硬盤
[root@xiao?~]#?mdadm?/dev/md0?-r?/dev/sda6 mdadm:?hot?removed?/dev/sda6?from?/dev/md0
4.9添加一個新硬盤作為熱備份盤
[root@xiao?~]#?fdisk?/dev/sda WARNING:?DOS-compatible?mode?is?deprecated.?It's?strongly?recommended?to ?????????switch?off?the?mode?(command?'c')?and?change?display?units?to ?????????sectors?(command?'u'). Command?(m?for?help):?n First?cylinder?(11014-13054,?default?11014):? Using?default?value?11014 Last?cylinder,?+cylinders?or?+size{K,M,G}?(11014-13054,?default?13054):?+1G Command?(m?for?help):?t Partition?number?(1-9):?9 Hex?code?(type?L?to?list?codes):?fd Changed?system?type?of?partition?9?to?fd?(Linux?raid?autodetect) Command?(m?for?help):?p Disk?/dev/sda:?107.4?GB,?107374182400?bytes 255?heads,?63?sectors/track,?13054?cylinders Units?=?cylinders?of?16065?*?512?=?8225280?bytes Sector?size?(logical/physical):?512?bytes?/?512?bytes I/O?size?(minimum/optimal):?512?bytes?/?512?bytes Disk?identifier:?0x0008ed57 ???Device?Boot??????Start?????????End??????Blocks???Id??System /dev/sda1???*???????????1??????????26??????204800???83??Linux Partition?1?does?not?end?on?cylinder?boundary. /dev/sda2??????????????26???????10225????81920000???83??Linux /dev/sda3???????????10225???????10486?????2097152???82??Linux?swap?/?Solaris /dev/sda4???????????10486???????13054????20633279????5??Extended /dev/sda5???????????10486???????10617?????1058045???fd??Linux?raid?autodetect /dev/sda6???????????10618???????10749?????1060258+??fd??Linux?raid?autodetect /dev/sda7???????????10750???????10881?????1060258+??fd??Linux?raid?autodetect /dev/sda8???????????10882???????11013?????1060258+??fd??Linux?raid?autodetect /dev/sda9???????????11014???????11145?????1060258+??fd??Linux?raid?autodetect Command?(m?for?help):?w The?partition?table?has?been?altered! Calling?ioctl()?to?re-read?partition?table. WARNING:?Re-reading?the?partition?table?failed?with?error?16:?設備或資源忙. The?kernel?still?uses?the?old?table.?The?new?table?will?be?used?at the?next?reboot?or?after?you?run?partprobe(8)?or?kpartx(8) Syncing?disks. [root@xiao?~]#?partx?-a?/dev/sda9?/dev/sda [root@xiao?~]#?mdadm?/dev/md0?--add?/dev/sda9 mdadm:?added?/dev/sda9 ? [root@xiao?~]#?mdadm?-D?/dev/md0 /dev/md0: ????????Version?:?1.2 ??Creation?Time?:?Wed?Dec?17?03:38:08?2014 ?????Raid?Level?:?raid5 ?????Array?Size?:?2113536?(2.02?GiB?2.16?GB) ??Used?Dev?Size?:?1056768?(1032.17?MiB?1082.13?MB) ???Raid?Devices?:?3 ??Total?Devices?:?4 ????Persistence?:?Superblock?is?persistent ????Update?Time?:?Wed?Dec?17?04:39:35?2014 ??????????State?:?clean? ?Active?Devices?:?3 Working?Devices?:?4 ?Failed?Devices?:?0 ??Spare?Devices?:?1 ?????????Layout?:?left-symmetric ?????Chunk?Size?:?512K ???????????Name?:?xiao:0??(local?to?host?xiao) ???????????UUID?:?bce110f2:34f3fbf1:8de472ed:633a374f ?????????Events?:?41 ????Number???Major???Minor???RaidDevice?State ???????0???????8????????5????????0??????active?sync???/dev/sda5 ???????3???????8????????8????????1??????active?sync???/dev/sda8 ???????4???????8????????7????????2??????active?sync???/dev/sda7 ???????5???????8????????9????????-??????spare???/dev/sda9
5.開機自動掛載
編輯/etc/fsab文件
/dev/md0 ?/mnt ? ext3 defaults 0 0
:wq
?
?
6.mdadm中文man(引用)
基本語法 ： mdadm [mode] [options]
[mode] 有7種：
Assemble：將以前定義的某個陣列加入當前在用陣列。
Build：Build a legacy array ，每個device 沒有 superblocks
Create：創建一個新的陣列，每個device 具有 superblocks
Manage： 管理陣列，比如 add 或 remove
Misc：允許單獨對陣列中的某個 device 做操作，比如抹去superblocks 或 終止在用的陣列。
Follow or Monitor:監控 raid 1,4,5,6 和 multipath 的狀態
Grow：改變r(jià)aid 容量或 陣列中的 device 數目
可用的 [options]:
-A, –assemble：加入一個以前定義的陣列
-B, –build：Build a legacy array without superblocks.
-C, –create：創建一個新的陣列
-Q, –query：查看一個device，判斷它為一個 md device 或是 一個 md 陣列的一部分
-D, –detail：打印一個或多個 md device 的詳細信息
-E, –examine：打印 device 上的 md superblock 的內容
-F, –follow, –monitor：選擇 Monitor 模式
-G, –grow：改變?cè)谟藐嚵械拇笮』蛐螒B(tài)
-h, –help：幫助信息，用在以上選項后，則顯示該選項信息
–help-options
-V, –version
-v, –verbose：顯示細節
-b, –brief：較少的細節。用于 –detail 和 –examine 選項
-f, –force
-c, –config= ：指定配置文件，缺省為 /etc/mdadm/mdadm.conf
-s, –scan：掃描配置文件或 /proc/mdstat以搜尋丟失的信息。配置文件/etc/mdadm/mdadm.conf
create 或 build 使用的選項:
-c, –chunk=:Specify chunk size of kibibytes. 缺省為 64.
–rounding=: Specify rounding factor for linear array (==chunk size)
-l, –level=:設定 raid level.
–create可用:linear, raid0, 0, stripe, raid1,1, mirror, raid4, 4, raid5, 5, raid6, 6, multipath, mp.
–build可用：linear, raid0, 0, stripe.
-p, –parity=：設定 raid5 的奇偶校驗規則:eft-asymmetric, left-symmetric, right-asymmetric, right-symmetric, la, ra, ls, rs.缺省為left-symmetric
–layout=:類似于–parity
-n, –raid-devices=:指定陣列中可用 device 數目，這個數目只能由 –grow 修改
-x, –spare-devices=：指定初始陣列的富余device 數目
-z, –size=：組建RAID1/4/5/6后從每個device獲取的空間總數
–assume-clean:目前僅用于 –build 選項
-R, –run:陣列中的某一部分出現在其他陣列或文件系統中時，mdadm會確認該陣列。此選項將不作確認。
-f, –force:通常mdadm不允許只用一個device 創建陣列，而且創建raid5時會使用一個device作為missing drive。此選項正相反。
-a, –auto{=no,yes,md,mdp,part,p}{NN}：
